►Présentation

Nous offrons un choix de plus de 1000 modèles de plinthes, bordures murales & décorations de sol en céramique.

Les bordures ou listel sont principalement utilisées entre deux rangées de carrelages muraux. Le plus souvent la longueur des borders correspond a celles du carrelage en 20x30, 25x40 and 30x45, 30x60 etc. pour des bordures en 7x20, 7x25, 8x30 etc..

Les plinthes sont principalement utilisées en bas d'un mur carrelé et il est moins important que leur longueur différe de cella du carrelage.

►Données techniques

Dimensions et qualité de surface

Test Item		Test Method	Provisions of Standard	Test Result	Judgement
Length and width		EN ISO10545-2	The deviation, in percent of the average size for each tile (2 or 4 sides) from the work size: ±0.5%	+0.10% ~ +0.21%	PASS
Length and width		EN ISO10545-2	The deviation, in percent of the average size for each tile (2 or 4 sides) from the average size of the 10 test spacimens (20 or 40 sides): ±0.5%	-0.05% ~ +0.05%	PASS
Thickness	Average size	EN ISO10545-2	---	6.9mm	---
Thickness	Devintion	EN ISO10545-2	The deviation, in percent of the average thickness of each tile from the work size thickness: ±10%	-0.33% ~ +1.63%	PASS
Straightness of sides		EN ISO10545-2	The maximum deviation from straightness,in percent, related to the corresponding work sizes: ±0.3%	-0.04% ~ +0.02%	PASS
Rectangularity		EN ISO 10545-2	The maximum deviation from rectangularity, in percent, related to the corresponding worksizes: ±0.5%	-0.07% ~ +0.09%	PASS
Surface flatness	Centre curvature	EN ISO10545-2	Centre curvature, related to diagonal calculated from work size: -0.3% ~ +0.5%	+0.14% ~ +0.12%	PASS
	Edge curvature		Edge cruvature, related to the corresponding work size: -0.3% ~ +0.5%	+0.02% ~ +0.10%	PASS
	Warpage		Warpage, related to the diagonal calculated from the work size: ±0.5%	-0.05% ~ +0.07%	PASS
Surface quality		EN ISO10545-2	A minimum of 95% of the tiles shall be free from visible defects that would impair the appearance of a major area of tiles	PASS	PASS

Propriétés physiques

Test Item	Test Method	Provisions of Standard	Test Result	Judgement
Water absorption	EN ISO10545-3	Average>10%, Individual minimum value 9%. When the average exceeds 20%, this shall be indicated by te manufacturer.	Average: 16.8% Individual minimum: 16.3%	PASS
Breaking strength	EN ISO10545-4	Thickness<7.5mm, Not less than 200N	614N	PASS
Modulus of rupture	EN ISO10545-4	Thickness≤7.5mm; minimum 15 MPa	26.1 MPa	PASS
Thermal shock resistance	EN ISO10545-9	Test method available	Fully resistant	PASS
Moisture expension	EN ISO10545-10	Test method available	<0.01%	---
Crazing resistance	EN ISO10545-11	Required	Fully resistant	PASS
Frost resistance	EN ISO10545-12	Required	Fully frost resistant	PASS

Propriétés chimiques

Test Item		Test Method	Provisions of Standard	Test Result	Judgement
Resistance in Chemicals	Resistance to low concentrations of acids and alkalis	EN ISO10545-13	Manufacturer to state classification	GLA	---
Resistance in Chemicals	Resistance to low household chemicals and swimming pool salts	EN ISO10545-13	Minimum GB	GA	PASS
Resistance to staining		EN ISO10545-14	Minimum Class 3	Class 5	PASS

►Conseils d'utilisation de la plinthes

Pour tous les grès cérame polis et les collections Rustic Stone l'idéal pour les plinthes est de choisir un modèle plus foncé dans la même collection qui sera coupé selon vos besoins.
